Focus
High quality, full-function 14” optical comparators with the most advanced technology available
XY Travel
Standard: 12” x 5”
Focus™ Contour Projector® systems are high quality, full-function 14” optical comparators with the most advanced technology available and offer:
Vectored light control – Versatile TruLight® LED lighting illumination
Keep lenses safe and ready for use – 3 position internal lens turret
Ideal for real world, shop floor environments in a benchtop configuration – Rigid, all steel construction and solid metal castings
Optional VidiProbe video measurement, optional motorized servo drives, and optional Projectron automatic internal edge detection
Technical Data
XY Travel
Standard
12” x 5”
Optics
Lens Options
10X, 20X, 31.25X, 50X, 100X
Illumination
Profile Light, Coaxial Light, and Oblique Surface Illumination
Screen
16” diameter, 14” viewable ground glass screen, with integral hood, 90° centerlines and clips for mounting overlay charts
WorkTable
Standard
Manual, hard coat anodized aluminum with dovetail slot and ±6.5° helix angle range
Optional
Motorized with variable speed joystick
Sensors & Accessories
Options/Accessories
| Standard | Optional | |
|---|---|---|
| XY Travel Range | 12” x 5” | |
| Helix Angle Range | ± 6.5° with pivoting worktable assembly and zero stop | |
| Z Focus Travel | 1.25” with precision fine adjustment | |
| Throat Clearance | 8.1” | |
| XY Scale Resolution | 0.00004” | |
| XY Drive System | Manual, with quick release X-axis and fine adjustment knob in X | Motorized with variable speed joystick control and manual fine adjustments |
| Worktable | Hardcoat anodized aluminum with fixturing slot, 16” x 4.75” | |
| Recommended Maximum Load Capacity | 45 lb | |
| Optical System | Telecentric, with upright, reversed image | |
| Optical Options1 | Adjustable direct projection iris; Overscreen Fresnel lens; High performance profile light collimator; Surface concentrator (requires optional surface light); VidiProbe video automation package | |
| Edge Detection2 | Projectron® internal automatic edge detection | |
| Screen | 16” diameter, 14” viewable ground glass screen, with integral hood, 90° centerlines and clips for mounting overlay charts | |
| Protractor | Digital screen display, ± 360° readout with 1’ (0.017°) resolution | |
| Working Distance | 3.9” | |
| Lens | 10x, 20x, 31.25x, 50x, 100x | |
| Lens Mount | Three position lens turret, manual, internal, with magnification display | |
| Illumination | ALL LED with continuously variable intensity green profile light, white through-the-lens coaxial surface light, and oblique (dark field) ring light with 8 white sectors and 6 switch-selectable patterns | |
| DRO | Q-Check® | |
| Software | Measure-X Measure and Compare (included with VidiProbe) Measure-X Analyze (optional with VidiProbe) Measure-X Offline OGP® EVOLVE® SPC |
|
| Accessories | Rotary indexer; Overhead light shield; Fixture and calibration reticles; Overlay charts; Heavy duty cabinet stand with storage space; Ergonomic, motorized adjustable height stand | |
| Power Requirements | 100-120 VAC or 200-240 VAC, 50/60 Hz, 1 phase, 800 W | |
| Safe Operating Environment | 15-30 °C, non-condensing | |
-
1 High performance profile light collimator and surface concentrator for use with lenses of 50x magnification and higher
2 Projectron intended for use with lenses of 50x magnification and lower
Last updated: May 2023
