SmartScope Comparison


	E-Series	M-Series	Quest/Vantage
Category	General Purpose	Enhanced Accuracy	Ultimate Accuracy
Applications	Video Measurement	Multisensor Measurement	Advanced Metrology
Accuracy	Consistent	Enhanced	Higest Precision-Optimized
Optics	High Resolution	Ultra-High	Highest Precision
Optional Sensors	Tactile	Tactile & Non-Contact	Advanced Tactile & Non-Contact
Value	Entry Level - High ROI	Expanded Versatility	Maximum Capability

Available Options
	E-Series	M-Series	Quest/Vantage
Touch Probe	●	●	●
3rd & 4th Axis Rotary Indexers	●	●	●
Scanning Probe		●	●
Feather Probe		●	●
Grid Projector		●	●
TTL Laser		●	●
Off Axis Laser		●	●
5th Axis Rotary Indexer		●	●
Volumetric Accuracy Specifications		●	●
TeleStar plus TTL Laser			●
Articulating Probe Head			●
Articulating Linear Motors			●

Optical Specifications
	E-Series	M-Series	Quest/Vantage
Optical System	IntelliCentric-E	IntelliCentric-M	TeleStar®
Telecentric	Yes	Yes	Yes
Distortion-Free	Yes	Yes	Yes
Magnification Change	Instant	Instant	Motorized
Zoom	VIRTUAL ZOOM™	VIRTUAL ZOOM™	Digital
Max Field of View	7.0 x 5.2 mm	8.0 x 8.0 mm	8.0 x 6.0 mm
Max Depth of Field	0.5 mm	2.0 mm	3.0 mm
Minimum Feature Size	10 μm	5 μm	2.5 μm
Working Distance	62 mm	68 mm	65 mm
