OGP SmartScope Quest technology leaves its mark on precision stampings specialist Batten & Allen

About the company

Batten & Allen is a precision stampings specialist based in Cirencester, Gloucestershire, UK. The privately owned company competes successfully with rivals in Asia for contracts to supply component quantities that run into hundreds of millions per month.

Phil Purser

Management Systems Representative Batten & Allen Ltd

The Challenge

"Component complexity would often mean two set-ups were required to inspect the part which in turn meant setting up both machines."

Precision stampings specialist Batten & Allen Ltd is using a range of OGP SmartScope® machines for the measurement of its miniature parts.

Among the systems is a recently installed SmartScope Quest™ 250 multisensor measuring machine that is helping the company maintain quality excellence for a host of customers in sectors that include electronics, medical, automotive, telecommunications, and solar energy.

Based in Cirencester, Gloucestershire, UK, Batten & Allen deploys a program of continuous investment for manufacturing, testing and inspection, along with investment in the competence of its workforce. It is this progressive philosophy that sees the privately-owned company compete successfully with rivals in Asia and elsewhere for contracts to supply component quantities that run into hundreds of millions per month.

“If we encounter any disadvantages due to lower labor costs overseas, we manage to offset these by deploying a planned program of investment in the latest manufacturing and metrology systems,” explains Phil Purser, Batten & Allen’s Management Systems Representative.

A good example of Batten & Allen’s commitment in this area can be seen within the company’s quality department. Here, an array of OGP SmartScope video-based coordinate measuring machines (CMMs) are deployed to great effect, measuring components and features beyond the capability of many competitor machines.

“Originally we had two machines similar in principle to the OGP systems,” stated Purser. “However, component complexity would often mean two set-ups were required to inspect the part, which in turn meant setting up both machines and transferring components between the two. This was deemed inefficient and not in keeping with our production ethos.”

The OGP Solution

In 2004 an OGP SmartScope ZIP 250 was installed at the 100-employee company to perform the same task, but in a single operation. This was made possible through the advantage of z-axis functionality. Such was the success of the ZIP 250 that two identical models have since been added.

“Once we saw that our original ZIP 250 could meet our requirements we had no delay in committing to OGP technology moving forward, providing it represented the ‘best value’ solution,” said Purser. “By ‘best value’ I don’t mean the least expensive, but giving the best throughput, functionality, and all-around performance. We benchmarked OGP against the competition before buying our first ZIP 250 and this is something we continue to practice each time we specify a new system.”

The company’s most recent acquisition, a SmartScope Quest 250 multisensor measuring machine was no exception, and again Batten & Allen decided that OGP technology was the best match for its requirements. The SmartScope Quest is a high accuracy video measurement machine featuring innovative TeleStar® zoom optics, patented illumination, and field proven edge detection algorithms to ensure measurements are made to the tightest tolerances. TeleStar optics are fully telecentric for superior imaging, significantly advancing the accuracy capability for video metrology. Furthermore, SmartScope Quest is equipped with 0.1 μm scales (0.05 μm optional) and a supremely stable metrology platform to guarantee precision.

OGP SmartScope Quest 250 Metrology System

The Results

"The accuracy of our new SmartScope Quest 250 ensures we are future-proofed."

“The accuracy of our new SmartScope Quest 250 ensures we are future-proofed,” according to Purser. “The tightest tolerance currently specified on our parts is 0.05mm, which is a dimension we need to measure in the z-axis.”

Components at the ISO9001 and ISO14001 accredited company are stamped on automatic presses that also produce any forms required in the same hit. Dimensional measurement is required to check features that include diameters, pitches, widths, thicknesses, angles, and form positions.

With many of the parts and features being so small, illumination is a critical feature of successful measurement. The SmartScope Quest 250 multisensor measuring machine incorporates patented illumination technologies that include a fixed array of LED lights that track the x-axis and provide square-on profile lighting.

Surface illumination is provided by SmartRing™, OGP’s patented vector light that gives total control of lighting angles, making it easy to pick out important features for repeatable and accurate optical probing.

The excellent illumination also gives Batten & Allen the opportunity to take crisp and clear component images. This is handy when products are at the development stage and the company needs to discuss certain issues with the customer. Images can be sent by email and discussed by phone. SmartScope images are also used to create visual aids for personnel in the stamping shop. Images showing potential problems can help lead to early identification of a process wandering from its tolerance limits.

While Batten & Allen currently only uses video measurement functionality, the SmartScope Quest series has been designed from the ground up as a multisensor system able to synchronize touch and laser probes without compromising performance. In fact, Batten & Allen recently placed an additional order for a SmartScope Quest 250 coordinate measuring machine complete with laser probe.

Underside view of SmartRing LED lighting mounted to a metrology machine

The SmartScope Quest 250 is programmed by Batten & Allen’s quality engineers using OGP’s intuitive metrology software. Fully automatic measurement routines can be programmed in minutes and data outputs can be customized to meet specific reporting formats or used by analysis packages to compute 3D surface profiles, part-to-CAD comparisons, SPC, or for reverse engineering.

“We are very comfortable with OGP metrology software. We can program offline or online as the need requires. Typically, many of our parts are minor variations on similar themes, so it is sometimes quicker for us to make program changes at the machine. The average run time for our programs is around three minutes.”

"The machines have increased our accuracy capability and boosted our speed considerably – throughput has risen enormously"

Components manufactured by Batten & Allen are produced on automatic, high-speed presses. Specially designed tool sets typically produce a group of components in a single hit. The parts are then spooled onto a reel ready for the customer. Samples are provided at the end of each reel for all products. Each sample is visually inspected but dimensional checks are only performed in line with the relevant sampling plan (which is product-specific).

“Because many of the components need to have exceptional conductive properties, metals such as beryllium copper and selective gold plating are not uncommon,” said Purser. “Inspection has a vital role to play – if there is a problem at the start of a reel we need to stop the press and address the issue as soon as possible to avoid wasting expensive material. As part of our program of continuous improvement, if such a problem is highlighted by our SmartScope machines, we now have the ability to stop any of our presses remotely from the quality department.”

Purser further commented that the OGP machines have proven very reliable as the company has experienced very few issues with the ZIP models, which have now been in place for several years. “Overall we are very pleased with our SmartScope technology. The machines have increased our accuracy capability and boosted our speed considerably – throughput has risen enormously without increasing manpower.”
