TurnCheck Shaft Measuring Systems

Measure shafts, cylinders and other turned, ground, or extruded parts with speed and precision

TurnCheck™ systems are precision optical instruments designed to measure shafts and other cylindrical parts. Each member of the TurnCheck family is built for ease of use and consistent accuracy, even in difficult shop-floor conditions.

TurnCheck systems are built for the people who use them: With advanced optics, rugged materials, and intelligent controls to make set up and measurements fast, accurate and easy.

Accurate measurements in shop floor conditions where vibration and temperature variation may not be tightly controlledRugged baseplate with adjustable vibration damping leveling feet
Highly rigid support for the optical motion assemblyExtruded aluminum column with an internal lattice
Clear, highly accurate imagesIllumination system produces highly collimated light with a constant wavelength
Crisp, uniformly magnified image across the entire field of view, with no edge effects or exclusion zonesReceiving optics are fully telecentric with each element designed to eliminate distortion
